Siemens MICROMASTER 420 - Page 5

MICROMASTER 420/430/440, Getting Started Guide 10/14 - A5E02779537A3 5
160 mm
6.30"
55 mm
2.2"
Ø 4.5 mm
0.17"
Ø 4.8 mm
0.19"
174 mm
6.85"
138 mm
5.43"
Ø 5.5 mm
0.22"
204 mm
8.03"
174 mm
6.85"
Frame Size A
Frame Size D Frame Size E Frame Size F
Frame Size B Frame Size C
Ø 17.5 mm
0.68"
486 mm
19.13"
235 mm
9.25"
616.4 mm
24.27"
810 mm
31.89"
With
Filter
1110 mm
43.70"
Ø 17.5 mm
0.68"
Ø 15 mm
0.59"
235 mm
9.25"
300 mm
11.81"
Operator
Panel
Operator
Panel
Operator
Panel
Operator
Panel
Operator
Panel
MM420
MM440
MM420
MM440
MM420
MM430
MM440
MM430
MM440
MM430
MM440
MM430
MM440
Dimension Drawings
Maßbilder
Encombrements
Dibujos acotados
Disegni qotati
