MICROMASTER 411 &
COMBIMASTER 411
Operating Instructions Issue 03/01
User Documentation
6SE6400-5CA00-0BP0

Table of Contents

Questions and Answers

  • M
    Melissa Santos DDSJul 29, 2025
    What to do if Siemens MICROMASTER 411 Inverter motor fails to start after ON command?
    • C
      Charlene TateJul 29, 2025
      If the motor fails to start after the ON command, verify that a valid ON signal is present. Also, check that P0700 = 2 for Terminal I/O control or P0700 = 1 for BOP control. Finally, ensure that the setpoint is present (0 to 10 V on Terminal 7) or that the setpoint has been correctly entered into the appropriate parameter, depending on the setpoint source (P1000).
  • J
    James RamseyAug 13, 2025
    How to fix Siemens MICROMASTER 411 motor that won't run after changing parameters?
    • S
      Stacy CraigAug 13, 2025
      If the motor fails to run after you've changed the parameters, try resetting the inverter to its factory default parameter values. To do this, set P0010 = 30, then P0970 = 1, and press P. After resetting, use a switch between terminals 1 and 4 on the I/O board; the drive should now run to the defined setpoint, which is established by the analog input and/or control potentiometer.

Summary

Overview of MICROMASTER 411; COMBIMASTER 411

MICROMASTER 411; COMBIMASTER 411 Features

General description of the inverter range for controlling three phase AC induction motors.

Design and Characteristics

Details main characteristics, performance, and protection features of the inverters.

Installation Guide

Mechanical and Electrical Installation

Covers mechanical mounting for both inverter types and electrical connection procedures.

Commissioning Procedures

Block Diagram and General Information

Commissioning Steps and Operation

Outlines the commissioning procedure and general operation of the inverters.

Troubleshooting Inverter Issues

LED and BOP Troubleshooting

Faults and Alarms Reference

Lists and explains common fault and alarm codes encountered with the inverters.

Engineering Information

Current Limit, Overload, and Protection

Details current limiting, overload protection, and thermal protection mechanisms.

Control Modes, Braking, and Derating

Siemens MICROMASTER 411 Specifications

General IconGeneral
Control MethodV/f control, Vector control
Output Frequency0 - 650 Hz
Protection Class/Enclosure RatingIP20
Input Frequency47 - 63 Hz
Output Voltage0 - Input Voltage
Communication InterfacesPROFIBUS, RS485
Protection FeaturesOvervoltage, undervoltage, overcurrent, Overtemperature
Ambient Temperature-10 to +50 °C (14 to 122 °F)
