10 Engineering Information Issue 03/01
MICROMASTER 411 & COMBIMASTER 411 Operating Instructions
144 6SE6400-5CA00-0BP0
Table 10-7 BiCo connections (r2053 to r2294)
CO CO
BO BO
COBO
CO CO CO CO CO CO CO CO
ParNr
BiCo
2053 2054 2090 2091 2197 2224 2250 2260 2262 2266 2272 2273 2294
Parameter Number Source Name Functional Grouping CO: CB identification CO: CB diagnosis BO: ControlWord 1 from CB BO: Controlword 2 from CB CO/BO: Statusword 1 of monitor CO: Act. fixed PID setpoint CO: Output setpoint of the MOP CO: PID setpoint CO: PID filtered setpoint CO: PID feedback CO: PID scaled feedback CO: PID error CO: PID output
0731 CIB BI: Binary output 7
0800 CIB BI: Download parameter set 0 7
0801 CIB BI: Download parameter set 1 7
0840 CIB BI: CDS Bit 0 (local/remote) 7
0842 CIB BI: ON/OFF1 7
0844 CIB BI: ON/OFF1 reverse 7
0845 CIB BI: 1. OFF2 7
0848 CIB BI: 2. OFF2 7
0849 CIB BI: 1. OFF3 7
0852 CIB BI: 2. OFF3 7
1020 CIB BI: Pulse enable 7
1021 CIB BI: Fixed frequency selection bit 0 7
1022 CIB BI: Fixed frequency selection bit 1 7
1032 CIB BI: Fixed frequency selection bit 2 7
1035 CIB BI: Enable MOP (UP-command) 7
1036 CIB BI: Enable MOP (DOWN-command) 7
1055 CIB BI: Enable JOG right 7
1056 CIB BI: Enable JOG left 7
1074 CIB BI: Disable additional setpoint 7
1110 CIB BI: Inhibit reverse direction 7
1113 CIB BI: Reverse 7
1124 CIB BI: Enable JOG ramp times 7
1140 CIB BI: RFG enable 7
1141 CIB BI: RFG start 7
1142 CIB BI: RFG enable setpoint 7
1230 CIB BI: Enable DC braking 7
2103 CIB BI: 1. Faults acknowledgement 7
2104 CIB BI: 2. Faults acknowledgement 7
2106 CIB BI: External fault 7
2220 CIB BI: Fixed PID setpoint selection bit 7
2221 CIB BI: Fixed PID setpoint selection bit 7
2222 CIB BI: Fixed PID setpoint selection bit 7
2235 CIB BI: Enable MOP (UP-command) 7
2236 CIB BI: Enable MOP (DOWN-command) 7
0771 CIW CI: DAC 8
1070 CID CI: Main setpoint 10
1071 CIF CI: Main setpoint scaling 10
1075 CID CI: Additional setpoint 10
1076 CIF CI: Additional setpoint scaling 10
2016 CIW CI: PZD to BOP-Link (USS) 20
2019 CIW CI: PZD to Comm-Link (USS) 20
2051 CIW CI: PZD to CB 20
2200 CIB BI: Enable PID controller 22
2253 CIF CI: PID setpoint 22
2254 CIF CI: PID trim source 22
2264 CIF CI: PID feedback 22
