10.9 Harmonic Currents
10.9.1 Harmonic currents with 1% mains impedance
Table 10-8 Three Phase 400 V Connection
MLFB Filter Type Power CT
(kW)
Fundamental
Amps
5th
Amps
7th
Amps
11th
Amps
13
th
Amps
17th
Amps
19
th
Amps
6SE6411-6UD13-7AA1 unfiltered
6SE6411-6BD13-7AA1 Class B
0.37
1.50 1.29 1.10
0.67 0.46 0.15 0.09
6SE6411-6UD15-5AA1 unfiltered
6SE6411-6BD15-5AA1 Class B
0.55
2.00 1.69 1.42
0.79 0.51 0.14 0.11
6SE6411-6UD17-5AA1 unfiltered
6SE6411-6BD17-5AA1 Class B
0.75
2.60 2.13 1.75
0.87 0.51 0.13 0.15
6SE6411-6UD21-1AA1 unfiltered
6SE6411-6BD21-1AA1 Class B
1.1
3.71 2.98 2.35
1.05 0.53 0.18 0.22
6SE6411-6UD21-5AA1 unfiltered
6SE6411-6BD21-5AA1 Class B
1.5
4.92 3.80 2.95
1.11 0.49 0.26 0.28
6SE6411-2UD22-2AA1 unfiltered
6SE6411-6BD22-2AA1 Class B
2.2
7.89 7.01 6.18
4.19 3.11 1.30 0.60
6SE6411-2UD23-0AA1 unfiltered
6SE6411-6BD23-0AA1 Class B
3
10.09 8.69 7.69
4.68 3.45 1.05 0.39
