3. INSTALLATION – MIDIMASTER Vector English
© Siemens plc 1999 G85139-H1751-U529-D1
27
4/8/9
Model 3 AC 208
- 240 V
3AC 380
-500 V
3 AC 525 -
575 V
Frame Sizes ( mm)
Notes
Frame Size
MDV220/4
MDV400/4
MDV550/2
MDV550/4
MDV750/2
MDV750/3
MDV750/4
MDV1100/2
MDV1100/3
MDV1100/4
MDV1500/2
MDV1500/3
MDV1500/4
MDV1850/2
MDV1850/3
MDV1850/4
MDV2200/2
MDV2200/3
MDV2200/4
MDV3000/2
MDV3000/3
MDV3000/4
MDV3700/2
MDV3700/3
MDV3700/4
MDV4500/2
MDV4500/3
MDV5500/3
MDV7500/3
-
-
4
-
4
-
-
5
-
-
6
-
-
6
-
-
6
-
-
7
-
-
7
-
-
7
-
-
-
-
-
-
-
-
4
-
-
4
-
-
5
-
-
5
-
-
6
-
-
6
-
-
6
-
-
7
7
7
4
4
-
4
-
-
4
-
-
4
-
-
5
-
-
5
-
-
6
-
-
6
-
-
6
-
-
-
IP21 / NEMA 1
W H D W1 H1
4 = 275 x 450 x 210 235 430
5 = 275 x 550 x 210 235 530
6 = 275 x 650 x 285 235 630
7 = 420 x 850 x 310 374 830
IP20/NEMA 1 with integrated EMC class
A filter
W H D W1 H1
4 = 275 x 700 x 210 235 680
5 = 275 x 800 x 210 235 780
6 = 275 x 920 x 285 235 900
7 = 420 x 1150x 310 374 1130
IP56 / NEMA 4/12
W H D W1 H1
4 = 360 x 675 x 376 313 649
5 = 360 x 775 x 445 313 749
6 = 360 x 875 x 505 313 849
7 = 500 x 1150 x 595 451 1122
Note:
Dimension D includes the front
control panel.
If a Clear Text Display (OPM2) is
to be included, an additional
30mm will be required.
Filtered MIDIMASTER Vector
versions are available up to 460V
mains supply only.
Note:
Dimension D includes the front
panel access door.
Figure: 3.1.2 (continued)
