Siemens MIDIMASTER Vector User Manual

8. SPECIFICATIONS English
© Siemens plc 1999 G85139-H1751-U529-D1
69
4/8/9
9
525V - 575 V Three Phase MIDIMASTER Vector Inverters
Order No. - IP21 / NEMA 1 (6SE32..)
Order No. - IP56 / NEMA 4/12 (6SE32..)
13-8FG40
13-8FS45
16-1FG40
16-1FS45
18-0FG40
18-0FS45
21-1FG40
21-1FS45
21-7FG40
21-7FS45
22-2FH40
22-2FS45
22-7FH40
22-7FS45
Inverter model MDV220/4 MDV400/4 MDV550/4 MDV750/4 MDV1100/4 MDV1500/4 MDV1850/4
Constant Torque (CT)
Variable Torque (VT)
CT VT CT VT CT VT CT VT CT VT CT VT CT VT
Input voltage range 3 AC 525V - 575 V +/-15%
M o t o r o u t p u t r a t i n g ( k W / h p ) 2.2 / 3 4 / 5 4 / 5 5 .5 / 7.5 5.5 / 7.5 7.5 / 10 7.5 / 1 0 11 / 15 11 / 15 15 / 20 15 / 2 0 18.5/ 2 5 1 8.5/
25
22 / 30.
Continuous output (kVA) @ 575V 3.9 6.1 6.1 9.0 9.0 11 13. 9 16.9 19.4 21.9 23.5 26.9 28.4 31.8
Output current (max. continuous) @ 575 V
(A)
3.9 6.1 6.1 9.0 9.0 11 11. 0 17.0 17.0 22.0 22.0 27.0 27.0 32.0
Input current (max.) (A) 7 10 12 18 24 29 34
Recommended mains fuse (A) 10 16 25 32 40
Fuse order code 3NA3803 - 6 3NA3805 - 6 3NA3810 - 6 3NA3814 - 6 3NA3820 - 6
Recommended lead Input (min.) 1.5 2.5 4 6 10
cross-section (mm
2
)
Output (min.) 1.5 2.5 4 6
Dimensions (mm) IP21 / NEMA 1 275 x 450 x 210 275 x 550 x 210
(w x h x d)
IP56 / NEMA 4/12 360 x 675 x 351 360 x 775 x 422
Weight (kg) IP21 / NEMA 1 11.0 11.5 11.5 11.5 12.0 16.0 17.0
IP56 / NEMA 4/12 22.0 24.0 26.0 29.0 30.0 39.0 40.0
525V - 575 V Three Phase MIDIMASTER Vector Inverters
Order No. - IP21 / NEMA 1 (6SE32..)
Order No. - IP56 / NEMA 4/12 (6SE32..)
23-2FJ40
23-2FS45
24-1FJ40
24-1FS45
25-2FJ40
25-2FS45
Inverter model MDV2200/4 MDV3000/4 MDV3700/4
Constant Torque (CT)
Variable Torque (VT)
CT VT CT VT CT VT
Input voltage range 3 AC 525V - 575 V +/-15%
Motor output rating (kW/hp) 22 / 30 30 / 40 30 / 40 37 / 50 37 / 50 45 / 60
Continuous output (kVA) @ 575V 33.6 40.8 44.6 51.7 54.4 61.7
Output current (max. continuous) @ 575 V (A) 32.0 41.0 41.0 52.0 52.0 62.0
Input current (max.) (A) 45 55 65
Recommended mains fuse (A) 50 63 80
Fuse order code 3NA3820 - 6 3NA3822 - 6 3NA3824 - 6
Recommended lead Input (min.) 10 16 25
cross-section (mm
2
)
Output (min.) 10 16
Dimensions (mm) IP21 / NEMA 1 275 x 650 x 285
(w x h x d)
IP56 / NEMA 4/12 360 x 875 x 483
Weight (kg) IP21 / NEMA 1 27.5 28.0 28.5
IP56 / NEMA 4/12 50.0 52.0 54.0
