Page 2 Milltronics MLC Belt Scale – INSTRUCTION MANUAL 7ML19985FF01
Specifications
Accuracy
• ±1.0% of totalization over 5 to 1 operating range
Belt Width
• metric: 450 to 1200 mm
• imperial: 18 to 48"
Belt Speed
• 2.0 m/s (400 fpm) maximum
Capacity
• up to 50 t/h (depending on loading and belt speed parameters)
Conveyor Incline
• ±20º from horizontal, fixed incline
• up to ±30º with reduced accuracy
Conveyor Idler Profile
•horizontal
Idler Diameter
• metric: 50 or 60 mm
• imperial: 1.90"
Idler Spacing
• 0.5 to 1.5 m (1.5 to 5 ft)
Loading
• Minimum 1.0 kg/m (0.6 lbs/ft)
• Maximum 30 kg/m (20 lbs/ft)
Load Cell
• excitation: 10 V DC nominal, 15 V DC maximum
• output: 2 mV/V excitation at rated load cell capacity
• non-linearity: 0.03% of rated output
• hysteresis: 0.05% of rated output
• non-repeatability: 0.03% of rated output
• capacity: 10 or 20 lbs.
• overload: safe 150% of rated capacity, ultimate 300% of rated capacity
•temperature:
-40 to 85ºC (-40 to 185ºF) operating range
-10 to 60ºC (14 to 140ºF) compensated
• stainless steel construction
• mounting dimensions: identical for all capacities
Hazardous Locations
• with the use of approved intrinsically safe barrier strips
Approvals
•CE
1
1.
EMC performance available upon request.
