1 - 1
Siemens-Elema AB SPR8-220.091.01 Page 1 of 2 MOBILETT Plus HP
Solna, Sweden Rev. 03 03.03 SPS-UD Service
Prerequisites 1
General 1
These instructions describe how to replace the inverter with part no. 65 08 654 on the
MOBILETT Plus HP.
The inverter D13 with part no. 65 08 654 is no longer available. It has been replaced by
65 28 306. When replacing the old type with the new one, the existing software has to be
replaced by V0.8H (part no. 65 86 114).
It is also necessary to equip the MOBILETT Plus HP with two extra capacitors. To make
room for the capacitors, the battery boxes and battery shelves must be replaced too.
Training of customer support engineers 1
Due to the technology used in this equipment, setup, service and maintenance should be
performed only by customer support engineers who have work authorization for
MOBILETT Plus.
Document required 1
Service Instructions for MOBILETT Plus HP.
Components included 1
The kit (part no. 65 53 981) contains the following parts:
Tools required 1
Standard tool kit.
Time required 1
Replacement of inverter, belonging software, battery boxes and battery shelves, and
installation of capacitor unit: approximately 2 1/2 hours for 1 person.
Article Quantity Part no.
Software kit: V0.8H 1 65 86 114
Inverter 1 65 28 306
Capacitor unit: M11 1 65 53 767
Battery box 4 65 53 700
Upper battery shelf 1 65 53 692
Lower battery shelf 1 65 53 684
Cable tie 15 65 01 712
Screw 2 62 29 178
Label 1 65 53 676
Repair Instruction (this instruction) 1 66 53 930
