Replacing the Inverter 2 - 3
Siemens-Elema AB SPR8-220.091.01 Page 3 of 6 MOBILETT Plus HP
Solna, Sweden Rev. 03 03.03 SPS-UD Service
Replace battery shelves 2
1. Pull out the power conversion unit, see chapter with same name in the document
Service Instructions.
2. Disconnect cable (1/Fig. 4) from P24 and P14 on the power conversion unit.
MOB00347
Fig. 4
2
4
4
P11
P40
3
3
3
M11
P42
P16
P24
P14
5
1
