Siemens MOBILETT Plus HP Service Manual

MOBILETT Plus HP SPR8-220.091.01 Page 2 of 6 Siemens-Elema AB
Service Rev. 03 03.03 SPS-UD Solna, Sweden
2 - 2 Replacing the Inverter
3. Open the holding belts (1/Fig. 2) and open the battery boxes by loosen three
screws (2/Fig. 2).
4.
Replace the old battery boxes.
Fasten the old top covers and tighten the holding belts.
Do not loosen the jumpers (1/Fig. 3) between the batteries.
Very high energy is stored in the batteries.
Life-threatening electric shock hazard exists.
MOB00353
Fig. 2
2
2
2
1
WARNUNGWARNING
MOB00110
Fig. 3
1
1
1
