Explanation of symbols
Numbering Plan
The key symbols show the optiPoint telephone user interface.
The functions on OpenStage and optiPoint telephones are comparable.
Symbol Explanation
ll, q, p ... Enter numbers, keys, password, internal or
external numbers, etc.
w Signaling with a short beep
n/t Lift/Replace the handset
s Start conversation
or
N
Service Menu
Programmable key is ON
Programmable key deleted
Blinking Programmable key
< > and : Navigation keys
- + Setting keys
or
n
Speaker on/off
O Mailbox key (OpenStage only)
Description HiPath 1120 HiPath 1150 HiPath 1190
External line 801 to 808 801 to 832 801 to 845
Extension, including S
0
11 to 30 11 to 60
610 to 645
101 to 240
Group of external lines 0, 890 to 899
Internal subscriber group 770 to 779
Hunt Groups (HG) 780 to 789
UCD subscriber group 790 to 799
Carrier 9
EVM - Default internal number 790
EVM - Message Ports 7491 to 7492
EVM - Virtual ports 744 to 747
Fax/DID - Virtual message ports 740 to 743
USB/CAPI line 10 100
Substitution for * and # 75 and 76 (accordingly)
Service Menu
Speaker
