Model PAD-5-CLSA
16
Siemens Industry, Inc. A6V101030359_en--_c
Building Technologies Division
4.3 Synchronization of Strobes
NACs 5-8 have the same functionality as NACs 1-4. So configuring for synchronization
is done through the Zeus programming tool. Since the NACs are all part of the same
PAD-5-MB, they will always be synchronized with each other. For multiple PAD-5-MBs
requiring synchronization, refer to the PAD-5-MB instructions, section 3.2.2.1
4.4 LED Indicators
LED Color Condition Meaning
H200 Yellow OFF NAC 5 (Class A or B) is in normal condition
ON NAC 5 (Class A or B) is in Trouble – See panel for
event message
Blinking
NAC 5 (Class A or B) has intermittent trouble (IN/OUT)
H202 Yellow OFF NAC 6 (Class B) is in normal condition – See panel for
event message
ON NAC 6 (Class B) is in Trouble – See panel for event
message
Blinking
NAC 6 (Class B) has intermittent trouble (IN/OUT)
H201 Yellow OFF NAC 7 Class B (NAC 2 Class A) is in normal condition
– See panel for event message
ON NAC 7 Class B (NAC 2 Class A) is in Trouble – See
panel for event message
Blinking
NAC 7 Class B (NAC 2 Class A)has intermittent
trouble (IN/OUT)
H203 Yellow OFF NAC 8 (Class B) is in normal condition – See panel for
event message
ON
NAC 8 (Class B)is in Trouble – See panel for event
message
Blinking
NAC 8 (Class B)has intermittent trouble (IN/OUT)
H300 Yellow ON Manual Disconnect Activate – Releasing cannot
activate
OFF
Manual Disconnect Not Active – Releasing is ready in
standby
