Model PAD-5-CLSA
1
LED Indicators
17
Siemens Industry, Inc.
A6V101030359_en--_c
Building Technologies Division
LED Color Condition Meaning
H204 Yellow Blinking Indicates main microprocessor is processing data
H501 Yellow OFF P2 - Normal condition
ON P2 - Trouble Condition
H500 Green OFF P2 – Pattern not Locatable
ON P2 – Pattern Locate
4.4.1 Switches
4.4.1.1 S202 Main Board RESET
Button Function Position Meaning
S202
Reset main microprocessor on
main board
Not pressed Normal
Pressed
Resets only the main microprocessor on
the periphery board.
4.4.1.2 S203 Reset for NAC Status LEDs
Button Function Position Meaning
S203
Switch resets current state of
Aux and NAC LEDs
Not pressed Previous state of NACs and Aux circuits
Steady: In Trouble
Blinking: Was in Trouble (Currently Normal)
Pressed Clears previous state and reports current
state of NACs and Aux circuits
4.4.1.3 S300 Releasing Manual Disconnect
Button Function Position Meaning
S300 Disconnects releasing service
from ability to activate
EN -Releasing is ready in standby
DIS Releasing cannot activate when in this
position
