Siemens PM250 - Page 50

Technical specifications
PM250 Power Module
50 Hardware Installation Manual, 09/2012, A5E01003502B AD
Table 6- 6 Frame Sizes F, 3 AC 380 V … 480 V, ± 10%
filtered 0BE34-5AA0 0BE35-5AA0 0BE37-5AA0
Order No.
unfiltered
6SL3225-
0BE34-5UA0 0BE35-5UA0 0BE37-5UA0
kW 45 55 75 Rated power based on HO-
loading
hp 60 75 100
Power Loss kW 1.5 2.0 2.4
Input base load current (HO) A 84 102 135
Output base load current (HO) A 90 110 145
Input base load current (LO) A 102 135 166
Output base load current (LO) A 110 145 178
Fuse A 160 200 250
l/s 94 94 117 Required cooling air flow
CFM 200 200 250
mm
2
35.0 … 120 35.0 … 120 35.0 … 120 Input Cable /
Output Cable
AWG 2 … 4/0 2 … 4/0 2 … 4/0
kg 51.0 51.0 51.0 filtered
lb 112 112 112
kg 36.0 36.0 36.0
Weight
unfiltered
lb 79.4 79.4 79.4
