Technical specifications
PM250 Power Module
Hardware Installation Manual, 09/2012, A5E01003502B AD
49
Table 6- 4 Frame Sizes D, 3 AC 380 V … 480 V, ± 10%
filtered 0BE31-5AA0 0BE31-8AA0 0BE32-2AA0
Order No.
unfiltered
6SL3225-
0BE31-5UA0 0BE31-8UA0 0BE32-2UA0
kW 15 18.5 22 Rated power based on HO-
loading
hp 20 25 30
Power Loss kW 0.44 0.55 0.72
Input base load current (HO) A 30 36 42
Output base load current (HO) A 32 38 45
Input base load current (LO) A 36 42 56
Output base load current (LO) A 38 45 60
Fuse A 50 63 80
l/s 22 22 39 Required cooling air flow
CFM 47 47 83
mm
2
10 … 35.0 10 … 35.0 10 … 35.0 Input Cable /
Output Cable
AWG 7 … 2 7 … 2 7 … 2
kg 15.4 15.4 16.0 filtered
lb 34.0 34.0 35.3
kg 13.0 13.0 13.0
Weight
unfiltered
lb 28.7 28.7 28.7
Table 6- 5 Frame Sizes E, 3 AC 380 V … 480 V, ± 10%
filtered 0BE33-0AA0 0BE33-7AA0
Order No.
unfiltered
6SL3225-
0BE33-0UA0 0BE33-7UA0
kW 30 37 Rated power based on HO-
loading
hp 40 50
Power Loss kW 1.0 1.3
Input base load current (HO) A 56 70
Output base load current (HO) A 60 75
Input base load current (LO) A 70 84
Output base load current (LO) A 75 90
Fuse A 100 125
l/s 22 39 Required cooling air flow
CFM 47 83
mm
2
25.0 … 35.0 25.0 … 35.0 Input Cable /
Output Cable
AWG 3 … 2 3 … 2
kg 21.0 21.0 filtered
lb 46.3 46.3
kg 16.0 16.0
Weight
unfiltered
lb 35.3 35.3
