Technical specifications
PM250 Power Module
48 Hardware Installation Manual, 09/2012, A5E01003502B AD
Power Module Specifications
CAUTION
High Overload (HO) and Light Overload (LO) input currents
The input current at the rated operating point - applies for the short-circuit voltage of the line
supply V
k
= 1% referred to the rated Power Module power and a rated line supply voltage of
400 V.
Note
UL certified Fuses must be used
In order that the system is in compliance with UL, UL certified fuses, circuit-breaker or self
protected combination motor controller must be used.
Table 6- 3 Frame Sizes C, 3 AC 380 V … 480 V, ± 10%
Order No. filtered 6SL3225- 0BE25-5AA0 0BE27-5AA0 0BE31-1AA0
kW 5.5 7.5 11 Rated power based on HO-
loading
hp 7.5 10 15
Power loss kW 0.240 0.30 0.40
Input base load current (HO) A 13.2 19 26
Output base load current (HO) A 13.2 19 26
Input base load current (LO) A 18 25 32
Output base load current (LO) A 18 25 32
Fuse A 20 32 35
l/s 38 38 38 Required cooling air flow
CFM 80 80 80
mm
2
4.0 … 10 4.0 … 10 4.0 … 10 Input Cable /
Output Cable
AWG 12 … 8 12 … 8 12 … 8
kg 7.5 7.5 7.5 Weight
lb 17 17 17
