Siemens RDE100.1DHW Room thermostat with Auto Timer, independent DHW CB1N1423en_01
Building Technologies 2013-03-15
Dimensions
85
1
2
7
21.5
0.5
83.5
7.1
4.1
Ø80
Ø60
1423M01
Remarks
Heating:
Because of the unavoidable self heating effects of the electrical current, any loads
of more than 3 Amperes connected to the unit can influence the control behavior
and temperature accuracy in a negative way.
All dimensions in mm
