70 / 94
Siemens RDF800KN.., RDF800KN/VB, RDD810KN/NF Basic documentation CE1P3174en
Smart Infrastructure 2020-02-21
Parameter
Name Range
RDD810KN/NF
RDF800KN..,
RDF800KN/VB
Dependencies
Diagnostics and test
d01 Application number
NONE = (no application)
2P = 2-pipe
2P3P = 2-pipe 3-position
2PEH = 2-pipe with electric heater
4P = 4-pipe
H =
heating
ü
d02 X1 state
0 = not activated (for DI)
1 = activated (DI)
0…49 °C = current temp. value (for AI)
00
= H/C input shorted
100 = H/C input open
ü ü
d03 X2 state
0 = not activated (for DI)
1 = activated (DI)
0…49 °C = current temp. value (for AI)
00 = H/C input shorted
100 = H/C input open
ü ü
d05
Test mode for checking the
Y1/Y2 actuator's running
direction
3)
"---" = no signal on outputs Y1 and Y2
OPE = output Y1 forced opening
CLO = output Y2 forced closing
x
ü
P46
3)
This parameter can only be exited when the setting is back at "---".
Touch + and – simultaneously to exit.
