Siemens RDH100RF/SET User Manual

13
Siemens
A6V10954418_en--_h
Smart Infrastructure
2022-12-06
Electrical connections
Connections terminals (via baseplate)
For solid wires
For stranded wires
Screw terminals
2 x 1.5 mm
2
1 x 2.5 mm
2
(min. 0.5 mm
2
)
Environmental conditions
Operation
Climatic conditions
Temperature
Humidity
IEC 60 721-3
Class 3K3
0…+45 °C
<85% r.h.
Storage and transport
Climatic conditions
Temperature
Humidity
Mechanical conditions
IEC 60 721-3
Class 2K3
-25…+70 °C
<93% r.h.
Class 2M2
Standards, directives and approvals
EU conformity (CE)
A6V101123354
Safety class
II as per EN 60 730-1
Degree of pollution
2
Color
Unit front
Signal-white RAL 9003
Base
Gray RAL 7035
Dimensions
83x104x32 mm
