Siemens RDH100RF/SET User Manual

12
Siemens
A6V10954418_en--_h
Smart Infrastructure
2022-12-06
General
Weight (including package)
RDH100RF/SE
475 g
Color of housing front
Signal-white RAL9003
Housing material
ABS (LCD lens:PC)
Receiver RCR100/433
General unit data
Operating voltage
*)
AC 230 V +10/-15%
Power
<10 VA
Frequency
50...60 Hz
*
EMI filter (e.g., KEILS EMI CW4L2-3-R) can be used to reduce EMI disturbance. See
Connection diagram [▶ 14].
Outputs
Switching capacity of relays
Voltage
Current
AC 24…250 V
8 (3) A
No internal fuse!
External preliminary protection with max. C 10 A circuit breaker required for all cases.
Switching outputs (LX, L1, L2)
Relay contacts
Switching voltage
Max. AC 250 V;
Min. AC 24 V
Switching current
Max. 8 A res., 3 A ind.
At AC 250 V
Min. 10 mA
Contact life at
AC 250 V
At 5 A res.
1 x 10
5
cycles (guide value)
Insulating strength
Between relay contacts
and coil
AC 5,000 V
Between relay contacts
(same pole)
AC 1,000 V

Siemens RDH100RF/SET Specifications

General

Brand	Siemens
Model	RDH100RF/SET
Category	Thermostat
Language	English
