Siemens REV23 User Manual

12/12
Siemens Building Technologies Room Temperature Controller REV23 CE1N2264en
HVAC Products 23.04.2002
E1 Cooling equipment
F1 Limit thermostat
F2 Safety limit thermostat
M1 Circulating pump
N1 Room temperature controller REV23
Y1 3-port valve with manual adjustment
Y2 Solenoid valve
Y3 Motorized 3-port valve
Y1
2261S04
M1
T
N1
Y4 Motorized 2-port valve
Circulating pump with precontrol via manual mixing valve
Dimensions
127
140
78.8
104.5
83.50
56
12
11.75
2264M01
30
Ø
6
0
ã2001 Siemens Building Technologies AG Subject to alteration

Siemens REV23 Specifications

General

Brand	Siemens
Model	REV23
Category	Temperature Controller
Language	English
