When the holiday period is over and the counter reads 00, the controller will resume the
operating mode selected last.
Using a suitable remote operating device, the controller can be switched to an inde-
pendently adjustable economy temperature
. Changeover is accomplished by the
making of a potentialfree contact connected to terminals T1 and T2. In that case, sym-
bol
will appear on the display. When the contact opens, the operating mode se-
lected last will be resumed.
Operation according to the setting made on
the controller
Continuously remote operation economy
temperature
T2
T1
2252Z05
T2
T1
2252Z06
Suitable remote operating devices:
telephone modem, manual switch, window switch, presence detector, central unit, etc.
Switching times Temperatures in ° C
1
st
period
2
nd
period
3
rd
period
Oper-
ating
mode
Block /
week-
days
1
st
period 2
nd
period 3
rd
period
Auto
1-5
Mo-Fr
6-7
Sa-Su
06.00
07.00
08.00
23.00
11.00 13.00 17.00 22.00
19
19
23
23
20 23 21 23 16
16
29
29
1-7
Mo-Su
00.00 24.00
19 23
1-7
Mo-Su
00.00 24.00
16 29
1-7
Mo-Su
00.00 24.00
5 35
10 30
Absence 12 30
Setpoint limitation
PID mode, self-learning
Optimum start control
Periodic pump run Off
Heating active
Remote operation
Remote operating
devices
Factory settings
Factory settings
heating engineer level
