Chapter 2
Installing Device
RUGGEDCOM RSG2100
Installation Guide
16 Wiring Examples
Section2.7.2
Wiring Examples
The following illustrate how to connect power to single and dual power supplies.
Figure9:Single AC Power Supply
Figure10:Single DC Power Supply
