Chapter 4
Technical Specifications
RUGGEDCOM RSG2100
Installation Guide
30 Failsafe Relay Specifications
Non-Hazardous Environments
Input Range
Power Supply Type
Minimum Maximum
Internal Fuse Rating
e f
Maximum Power
Consumption
g
24 VDC 10 VDC 36 VDC 6.3 A(F)
48 VDC 36 VDC 72 VDC 3.15 A(T)
HI (125/250 VDC)
h
88 VDC 300 VDC 2 A(T)
HI (110/230 VAC)
h
85 VAC 264 VAC 2 A(T)
28 W
e
(F) denotes fast-acting fuse
f
(T) denotes time-delay fuse.
g
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1 W less than fiber optic ports.
h
The HI power supply is the same power supply for both AC and DC.
Section4.2
Failsafe Relay Specifications
Parameter Value (Resistive Load)
Max Switching Voltage 240 VAC, 125 VDC
Rated Switching Current 2 A @ 240 VAC, 0.15 A @ 125 VDC, 2 A @ 30 VDC
Maximum Switching Capacity 150 W, 500 VA
Section4.3
Supported Networking Standards
Standard 10 Mbps Ports 100 Mbps Ports 1000 Mbps Ports Description
IEEE 802.3
ü
10BaseT/10BaseFL
IEEE 802.3u
ü
100BaseTX/100BaseFX
IEEE 802.3x
ü ü ü
Flow Control
IEEE 802.3z
ü
1000BaseLX
IEEE 802.3ab
ü
1000BaseTx
IEEE 802.3ad
ü
Link Aggregation
IEEE 802.1D
ü ü ü
MAC Bridges
IEEE 802.1D
ü ü ü
Spanning Tree Protocol (STP)
IEEE 802.1p
ü ü ü
Class of Service (CoS)
IEEE 802.1Q
ü ü ü
VLAN (Virtual LAN) Tagging
IEEE 802.1w
ü ü ü
Rapid Spanning Tree Protocol (RSTP)
