32 Fiber Optic Ethernet Port Specifications
10FL Ethernet Optical Specifications
Mode
Connector
Type
Cable
Type (µm)
Tx λ (nm)
n
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.) (km)
Power
Budget
(dB)
62.5/125 -16 -9 18
MM ST
50/125
850
-19.8 -12.8
-34 -11.2 2
14.2
n
Typical.
Fast Ethernet (10/100 Mbps) Optical Specifications
Mode
Connector
Type
Cable
Type (µm)
Tx λ (nm)
o
Tx min.
(dBm)
Tx max.
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Maximum
Distance
(km)
p
Power
Budget
(dB)
62.5/125 -19 12
MM ST
50/125
1300
-22.5
-14 -31 -14 2
8.5
62.5/125 -19 12
MM SC
50/125
1300
-22.5
-14 -31 -14 2
8.5
62.5/125 -19 12
MM MTRJ
50/125
1300
-22.5
-14 -31 -14 2
8.5
MM LC 62.5/125 1300 -19 -14 -32 -14 2 13
SM ST 9/125 1310 -15 -8 -32 -3 20 17
SM SC 9/125 1310 -15 -8 -31 -7 20 16
SM LC 9/125 1310 -15 -8 -34 -7 20 19
SM SC 9/125 1310 -5 0 -34 -3 50 29
SM LC 9/125 1310 -5 0 -35 3 50 30
SM SC 9/125 1310 0 5 -37 0 90 37
SM LC 9/125 1310 0 5 -37 0 90 37
o
Typical.
p
Typical distance. Dependent on the cable type, number of connectors and number of splices.
Gigabit Ethernet (1 Gbps) Optical Specifications
NOTE
These transceivers utilize a distributed feedback (DFB) type laser and are rated for -20 to 85 °C (-4 to
185 °F) operation only.
Mode
Connector
Type
Cable Type
(µm)
q
Tx λ (nm)
r
Tx
Minimum
(dBm)
s
Tx
Maximum
(dBm)
s
Rx
Sensitivity
(dBm)
s
Rx
Saturation
(dBm)
s
Maximum
Distance
(km)
t
Power
Budget
(dB)
50/125
MM LC
62.5/125
850 -9 -2.5 -20 0 0.5 11
