Operating Environment 33
Mode
Connector
Type
Cable Type
(µm)
q
Tx λ (nm)
r
Tx
Minimum
(dBm)
s
Tx
Maximum
(dBm)
s
Rx
Sensitivity
(dBm)
s
Rx
Saturation
(dBm)
s
Maximum
Distance
(km)
t
Power
Budget
(dB)
SM SC 9/125 1310 -10 -3 -20 -3 10 10
SM LC 9/125 1310 -9.5 -3 -21 -3 10 11.5
SM SC 9/125 1310 -5 0 -20 -3 25 15
SM LC 9/125 1310 -7 -3 -24 -3 25 17
q
All cabling is duplex type unless specified otherwise.
r
Typical.
s
All optical power numbers are listed as dBm averages.
t
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches and splices. Consult a Siemens
sales associates when determining maximum segment distances.
GBIC Gigabit (1 Gbps) Transceiver Specifications
NOTE
GBIC transceivers have a temperature range of -40 to 85 °C (-40 to 185 °F), unless specified otherwise.
Mode
Connector
Type
Cable
Type (µm)
Tx λ (nm)
u
Tx
Minimum
(dBm)
v
Tx
Maximum
(dBm)
v
Rx
Sensitivity
(dBm)
v
Rx
Saturation
(dBm)
v
Maximum
Distance
(km)
w
Power
Budget
(dB)
SM SC 9/125 1310 -9.5 -3 -21 -3 10 11.5
SM SC 9/125 1310 -7 -3 -24 -3 25 17
SM
x
SC 9/125 1550 0 5 -23 -3 70 23
u
Typical.
v
All optical power numbers are listed as dBm averages.
w
Typical distance. The maximum segment length is greatly dependent on factors such as fiber quality, and the number of patches and splices. Consult a Siemens
sales associates when determining maximum segment distances.
x
Operating temperature range of -20 to 85 °C (-4 to 185 °F) .
Section4.6
Operating Environment
Parameter Range Comments
Ambient Operating Temperature -40 to 85 °C (-40 to 185 °F) Ambient Temperature as measured from a 30 cm
radius surrounding the center of the enclosure.
Ambient Relative Humidity 5% to 95% Non-condensing
Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F)
