Siemens RUGGEDCOM RX1510 Installation Guide

Chapter 4
Technical Specifications
RUGGEDCOM RX1501
Installation Guide
38 Failsafe Relay Specifications
Section 4.2
Failsafe Relay Specifications
Maximum Switching Voltage Rated Switching Current Isolation
30 VDC 5 A
250 VAC 6.25 A
2800 VDC for 1 minute
Section 4.3
Copper Serial Port Specifications
Baud Rate Connector Isolation
1200 to 230400 kbps RJ45 2500 VDC for 1 minute
Section 4.4
Copper Ethernet Port Specifications
The following details the specifications for copper Ethernet ports that can be ordered with the RX1501.
Speed
d
Connector Mode Duplex
d
Cable
Type
e
Wiring Standard
f
Maximum
Distance
Isolation
g
10/100/1000TX RJ45 —
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100/1000TX 8-Pin A-Coded M12 —
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100/1000TX 8-Pin A-Coded M12 Controlled Bypass
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100/1000TX 8-Pin X-Coded M12 —
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100/1000TX 8-Pin X-Coded M12 Controlled Bypass
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100TX RJ45 —
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100TX 8-Pin A-Coded M12 —
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100TX 8-Pin A-Coded M12 Controlled Bypass
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100TX 4-Pin A-Coded M12 —
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
10/100TX 4-Pin A-Coded M12 Controlled Bypass
FDX/
HDX
> CAT-5 TIA/EIA T568A/B
100 m
(328 ft)
1.5 kV
d
Auto-negotiating.
e
Shielded or unshielded.
