Description of the device
3.4 Accessories
SCALANCE W760/W720
18 Operating Instructions, 07/2020, C79000-G8976-C322-12
Flexible connecting cable IWLAN QMA/N-Connect male/female
Adapter cable for connecting a MIMO antenna with QMA connectors with the flexible
connecting cables. Preassembled with two connectors QMA male and N-Connect female.
pack of 3
Length
Article number
1 m
6XV1875-5JH10
For railway applications, the following connecting cable is available Note: Scope of delivery:
Pack of 1
Length
Article number
1 m 6XV1875-5VH10
3.4.1.2 Antennas
Note
When you select an antenna, keep in mind the national approvals for your device.
You will find more detailed information in Link (
http://www.siemens.com/wireless-approvals).
The SCALANCE W1788-2IA uses internal omni antennas (3/4 dBi at 2.4 GHz or 5 GHz).
Type
Properties
Article number
IWLAN RCoax Antenna
ANT792-4DN
RCoax helical antenna with circular polariza-
tion for RCoax systems, 4 Bi, 2.4 GHz, IP65,
N-Connector female.
6GK5792-4DN00-0AA6
ANT792-6MN Omnidirectional antenna, mast/wall mount-
ing, 6 dBi 2.4 GHz, IP67, N-Connect female
6GK5792-6MN00-0AA6
ANT792-8DN Directional antenna, mast/wall mounting,
14 dBi 2.4 GHz, IP32, N-Connect female
6GK5792-8DN00-0AA6
IWLAN RCoax
ANT793-4MN
RCoax λ4 antenna with vertical polarization
for RCoax systems, 6 dBi, 5 GHz, IP65, N-
Connector female
6GK5793-4MN00-0AA6
ANT793-6DG Wide angle antenna, mast/wall mounting,
9 dBi 5 GHz, IP66/67, 2 x N-Connect female
6GK5793-6DG00-0AA0
ANT793-8DJ Directional antenna, mast/wall mounting,
18 dBi 5 GHz, IP67, 2 x N-Connect female
6GK5793-8DJ00-0AA0
ANT793-8DK Directional antenna, mast/wall mounting, 23
dBi 5 GHz, 2 x N-Connect female
6GK5793-8DK00-0AA0
ANT793-8DL Directional antenna vertical-horizontal polar-
ized, 5 GHz, 14dBi, IP66, 2xN-Connect
female
6GK5793-8DL00-0AA0
