Description of the device
3.5 LED display
SCALANCE W760/W720
20 Operating Instructions, 07/2020, C79000-G8976-C322-12
Note
ANT793-8DJ
The antenna ANT793
-8DJ may only be used with the flexible connecting cable 6XV1875-
5CH50 (5 m length) or 6XV1875
-5CN10 (10 m length). Other flexible connecting cables are
Only one antenna per device can be used (co
nnected to R1A1, R1A2 or R2A1, R2A2).
Note
ANT793-8DK
The antenna ANT793
-8DK may only be used with the flexible connecting cable 6XV1875-
5CN10 (10 m length). Other flexible connecting cables are not permitted.
device can be used (connected to R1A1, R1A2 or R2A1, R2A2).
3.5 LED display
Information on operating status and data transfer
On the front of the housing, several LEDs provide information on the operating status of the
device:
