Technical data
SCALANCE W760/W720
44 Operating Instructions, 07/2020, C79000-G8976-C322-12
SCALANCE W761/W722/W721
Design R-SMA female
Impedance 50 Ω nominal
Frequency range 2412 ... 2480 MHz
4920 ... 5875 MHz
Electrical data
Power supply
Supply voltage
24 VDC Safe Extra Low Voltage (SELV)
Permitted range
19.2 to 28.8 VDC
Design
Terminal block, 3 terminals
Fusing
2.5 A / 24 VDC
Current consumption
At 24 VDC / typical
150 mA
Power loss at 24 VDC
At 24 VDC / typical
3.6 W
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally / vertically
0 ℃ to +55 ℃
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation
≤ 95% at 25 °C, no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 55 °C
ambient temperature
Contaminant concentration
According to IEC 60721
Degree of protection
IP code
IP20
Dimensions and weight
Dimensions
W x H x D
50 x 114 x 74 mm
Weight
130 g
Installation options
Installation on a DIN rail
Mean time between failure (MTBF)
at 40 °C ambient temperature
106.51 years
