Description of the device
3.4 Accessories
SCALANCE W774-1 /W734-1
16 Operating Instructions, 01/2017, C79000-G8976-C325-08
Component
Description
Article number
IE FC TP FLEXIBLE
CABLE GP 2X2
(PROFINET type B)
Flexible bus cable, TP installation cable, flexible
wires, shielded, CAT 5
Sold by the meter
6XV1 870-2B
IE FC TP TRAILING
CABLE 2X2
(PROFINET type C)
Highly flexible bus cable, TP installation cable for
connection to FC OUTLET RJ-45, for use in drag
chains, 4-wire, shielded, CAT 5
Sold by the meter
6XV1 840-3AH10
IE TP TORSION CABLE
2X2
(PROFINET type C)
Highly flexible bus cable, TP installation cable for
use in highly flexible applications (torsion), 4-wire
Sold by the meter
6XV1 870-2F
IE CONNECTING CABLE
M12-180/IE RJ45
Flexible IE connecting cable, 4-wire, preassem-
bled with a 4-pin M12 plug (D-coded) and an IE
FC RJ-45 plug 145
6XV1 871-5T*
IE CONNECTING CABLE
M12-180/M12-180
Flexible IE connecting cable, 4-wire, preassem-
bled with two 4-pin M12 plugs (D-coded)
6XV1 870-8A*
* Available in different lengths
Cabinet feedthrough
Component
Description
Article number
IE M12 PANEL
FEEDTHROUGH
Cabinet feedthrough for conversion from M12
connector technology (D-coded, IP65) to RJ-45
connector technology (IP20)
pack of 5
6GK1 901-0DM20-2AA5
IE M12 PANEL
FEEDTHROUGH
PRO
Cabinet feedthrough for conversion from M12
connector technology (D-coded, IP65) to M12
connector technology (D-coded, IP65)
pack of 5
6GK1 901-0DM30-2AA5
IE M12 PANEL
FEEDTHROUGH
4X2
Cabinet feedthrough for conversion from M12
connector technology (X-coded, IP65/67) to RJ-45
connector technology (X-coded, IP20)
pack of 5
6GK1 901-0DM40-2AA5
N-Connect/N-
Connect fe-
male/female Panel
Feedthrough
Panel feedthrough for wall thicknesses up to a
maximum of 4.5 mm, two N-Connect female con-
nectors.
6GK5 798-2PP00-2AA6
N-Connect/SMA-
Connect fe-
male/female Panel
Feedthrough
Panel feedthrough for wall thicknesses up to a
maximum of 5.5 mm, two N-Connect/SMA female
connectors.
6GK5 798-0PT00-2AA6
