3.4 Accessories
SCALANCE W774-1 /W734-1
Operating Instructions, 01/2017, C79000-G8976-C325-08
17
Energy cable
Component
Description
Article number
Energy cable 2
x 0.75
Energy cable for connection of signaling contact and power
supply 24 VDC, stranded wire 2 x 0.75 mm
2
, capable of trail-
ing, not assembled
Sold by the meter
6XV1 812-8A
Robust Energy
Cable 4 x 0.75
Energy cable for connection of power supply 24 VDC, 4-wire
stranded 4 x 0.75 mm
2
, robust, flexible, not assembled
Sold by the meter
6XV1 801-2A
M12 PLUG-IN
CABLE
Flexible plug-in power cable to connect the power supply 24
VDC, 4-wire, preassembled with a 4-pin M12 plug and an
M12 socket (A-coded)
6XV1 801-5D*
* Available in different lengths
Socket
Component
Description
Article number
IE POWER M12
CABLE CONNECTOR
PRO
Socket for the 24 VDC power supply. 4-pin, A-
coded
pack of 3
6GK1 907-0DC10-6AA3
Lightning protection
Component
Description
Article number
LP798-1N Lighting protector with N/N female/female connector with
gas discharge technology
6GK5798-2LP00-2AA6
LP798-2N Lighting protector with N/N female/female connector with
quarter wave technology
6GK5798-2LP10-2AA6
Terminating resistor
Component
Description
Article number
TI795-1N Electrical connection
N-Connect, male
6GK5795-1TN00-1AA0
