Description of the device
3.3 Components of the product
SCALANCE W788-x / W748-1
14 Operating Instructions, 09/2017, A5E03678333-12
Components of the product
The following components are supplied with the product:
● SCALANCE W7x8
● Only with device variant M12 / IP65:
– 2 protective caps for the M12 sockets
● Only with device variant RJ-45 / IP30:
– 4-pin terminal block for the supply voltage
– 4-pin terminal block for the digital input/output
● 2 screws for mounting on an S7-300 standard rail
● SIMATIC NET Industrial Wireless LAN CD
Note
The mounting set with the holding plate does not ship with t
he device, see Accessories
Please check that the consignment you have received is complete. If the consignment is
incomplete, contact your supplier or your local Siemens office.
