Siemens SCALANCE W788 User Manual

Description of the device
3.4 Accessories
SCALANCE W788-x / W748-1
Operating Instructions, 09/2017, A5E03678333-12
19
Flexible connecting cable IWLAN QMA/N-Connect male/female
Adapter cable for connecting a MIMO antenna with QMA connectors with the flexible
connecting cables. Preassembled with two connectors QMA male and N-Connect female.
pack of 3
Length
Article number
1 m
6XV1875-5JH10
For railway applications, the following connecting cable is available Note: Scope of delivery:
Pack of 1
Length
Article number
1 m
6XV1875-5VH10
3.4.1.2
Antennas
Note
When you select an antenna, keep in mind the national approvals for your device.
You
will find more information in the following Link (https://www.siemens.com/wireless-
approvals
)
The SCALANCE W786-2IA RJ-45 uses internal omni antennas (3/4 dBi at 2.4 GHz or 5
GHz).
Type
Properties
Article number
ANT792-4DN RCoax helical antenna, circular polariza-
tion, 4 dBi, 2.4 GHz, N-Connect female.
6GK5792-4DN00-0AA6
ANT792-6MN Omni antenna, mast/wall mounting, 6 dBi
2.4 GHz, N-Connect female
6GK5792-6MN00-0AA6
ANT792-8DN Directional antenna, mast/wall mounting,
14 dBi 2.4 GHz, N-Connect female
6GK5792-8DN00-0AA6
ANT793-4MN RCoax λ5/8 antenna with vertical polari-
zation, 6 dBi, 5 GHz, N-Connect female.
6GK5793-4MN00-0AA6
ANT793-6DG Wide angle antenna, mast/wall mount-
ing, 9 dBi 5 GHz, 2 x N-Connect female
6GK5793-6DG00-0AA0
ANT793-6DT Wide angle antenna (MIMO), mast/wall
mounting, 8 dBi 5 GHz, 3 x QMA con-
nector female
6GK5793-6DT00-0AA0
ANT793-6MN Omni antenna, mast/wall mounting, 5 dBi
5 GHz, N-Connect female
6GK5793-6MN00-0AA6
ANT793-8DJ Directional antenna, mast/wall mounting,
18 dBi 5 GHz, 2 x N-Connect female
6GK5793-8DJ00-0AA0
ANT793-8DK Directional antenna, mast/wall mounting,
23 dBi 5 GHz, 2 x N-Connect female
6GK5793-8DK00-0AA0
