Description of the device
3.4 Accessories
SCALANCE W788-x / W748-1
16 Operating Instructions, 09/2017, A5E03678333-12
For the RJ-45 variants the following plug-in connector is required:
Component
Description
Article number
IE FC RJ-45
PLUG 180 4x2
Industrial Ethernet FastConnect RJ45
Plug 180 4x 2, RJ45 plug-in connect-
or; CAT6A; (10/100/1000/10000
Mbps) with rugged metal housing and
FC connector technology, for IE FC
Cable 4x 2 (24 AWG); 180° cable
outlet
1 connector per
package
6GK1901-1BB12-2AA0
10 connectors per
package
6GK1901-1BB12-2AB0
50 connectors per
package
6GK1901-1BB12-2AE0
Cables Industrial Ethernet
Component
Description
Article number
IE FC TP cable 4 x 2 Industrial Ethernet FastConnect TP standard
cable GP 4x 2, TP installation cable CAT6A for
connection to IE FC RJ45 Plug 4x 2, 24 AWG
Sold by the meter
6XV1878-2A
* Available in different lengths
Cabinet feedthrough
Component
Description
Article number
IE M12 PANEL
FEEDTHROUGH 4X2
Cabinet feedthrough for conversion from M12
connector technology (X-coded, IP65/67) to RJ-
45 connector technology (X-coded, IP20)
pack of 5
6GK1901-0DM40-2AA5
N-Connect/N-Connect
female/female Panel
Feedthrough
Panel feedthrough for wall thicknesses up to a
maximum of 4.5 mm, two N-Connect female
connectors.
6GK5798-2PP00-2AA6
N-Connect/SMA-
Connect fe-
male/female Panel
Feedthrough
Panel feedthrough for wall thicknesses up to a
maximum of 5.5 mm, two N-Connect/SMA female
connectors.
6GK5798-0PT00-2AA6
