Description of the device
4.5 Components of the product
SCALANCE X-300
Operating Instructions, 05/2016, A5E01113043-20
99
Components of the product
Unpacking, checking
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
Do not use any parts that show evidence of damage!
Components of the product
The following components are supplied with a SCALANCE X-300:
● Device with C-PLUG exchangeable medium.
● A four-pin terminal block for the 24 VDC power supply.
● A two-pin terminal block for the signaling contact.
● Product CD with documentation and software.
X-300M components of the product
Note
When shipped, all devices have a C
-PLUG exchangeable medium.
Note
When shipped, the slots
for the media modules have a dummy cover fitted.
Note
Labels to identify the installed MM900 media modules are supplied with the modular devices
(M).
