Laptop
PC
PLC
Field devices
Operator
control and
monitoring
*B,.B;;B
Industrial Ethernet (Twisted Pair)
SCALANCE
XB004-1
SCALANCE
XB004-1
Industrial Ethernet (Fiber Optic)
Figure 3-2 Example of an electrical/optical star topology with SCALANCE XB004-1
Network topologies
SCALANCE XB-000
12 Operating Instructions, 01/2022, A2B00077300-11
