5.2 Types of installation
The devices can be installed in the following ways:
• Installation on a 35 mm DIN rail
• Wall mounting
WARNING
If the module is operated in an ambient temperature between 50 °C and 60 °C, the temperature
of the module housing may be higher than 60 °C. The device must therefore be installed so that
it is only accessible to service personnel or users that are aware of the reason for restricted
access and the required safety measures at an ambient temperature of 50 °C to 60 °C.
Installation clearance
Keep to the minimum clearances so that the convection ventilation of the device is not blocked.
• Below at least 10 cm
• Above at least 10 cm
See also
SIMATIC NET Industrial Ethernet TP and Fiber Optic Networks (http://
support.automation.siemens.com/WW/view/en/8763736)
Assembly and disassembly
5.2 Types of installation
SCALANCE XB-000
40 Operating Instructions, 01/2022, A2B00077300-11
