Siemens SCALANCE XB-000 User Manual

Technical speci󹪝cations
8
8.1 SCALANCE XB004-1
Table 8-1 Technical speci󹪝cations of the SCALANCE XB004-1
Technical speci󹪝cations
Article number
SCALANCE XB004-1 6GK5 004-1BD00-1AB2
Attachment to Industrial Ethernet
Quantity 4
Design RJ-45 jacks with MDI‑X pinning
Properties Half / full duplex
Transmission rate 10/100 Mbps
Optical connectors
Quantity 1
Design SC socket
Properties Full duplex acc. to 100Base-FX
Transmission rate 100 Mbps
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 to 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via IE FC RJ45 Outlet
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via IE FC RJ45 Outlet
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Optical parameters
Cable type Multimode glass FO cable, cable cross sections 62.5/125 μm and 50/125 μm
Permitted cable length (glass FO cable) Cable cross-section Permitted cable length
• 62.5/125 μm
• 50/125 μm
• 0 to 4,000 m
• 0 to 5,000 m
Electrical data
Power supply Rated voltage 24 V AC, 50/60 Hz
1)
24 V DC
Voltage range 19.2 to 28.8 V AC/DC Safety Extra Low Volt‐
age (SELV)
Design 3-terminal plug-in block
Current consumption Typically 24 V AC 230 mA
Typically 24 V DC 105 mA
SCALANCE XB-000
Operating Instructions, 01/2022, A2B00077300-11 57
