Siemens SCALANCE XB-000 User Manual

Technical speci󹪝cations
E󹪜ective power loss Typically 24 V AC 5.5 VA
Typically 24 V DC 2.5 W
Overvoltage protection at input PTC resettable fuse (0.5 A / 60 V)
Permitted ambient conditions
Ambient temperature During operation -10 ℃ to +60 ℃
During storage -40 ℃ to +80 ℃
During transportation -40 ℃ to +80 ℃
Relative humidity During operation ≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. +60 °C
ambient temperature
< 3,000 m above sea level at max. +55 °C
ambient temperature
< 4,000 m above sea level at max. +50 °C
ambient temperature
Design, dimensions and weight
Immunity EN 61000-6-2
Emission EN 61000-6-4
Degree of protection IP20
MTBF (EN/IEC 61709; 40 °C) 134 years
Housing material Polycarbonate (plastic)
Weight 165 g
Dimensions (W x H x D) 45 x 100 x 87 mm
Installation options
• Mounting on a DIN rail
• Wall mounting
Switching properties
Aging time 300 seconds / 45 seconds
1)
Max. number of learnable MAC ad‐
dresses
1024
Response to LLDP frames Blocking
Response to spanning tree BPDU
frames
Forwarding
CoS acc. to IEEE 802.1Q Yes
QoS priority queues 2 / 4
1)
IEEE 802.1Q tags (VLAN ID, priority)
transparent forwarding
Yes
Maximum frame size 1536 bytes
Forwarding of PRP frames (Parallel Re‐
dundancy Protocol)
Yes
Technical speci󹪝cations
8.1 SCALANCE XB004-1
SCALANCE XB-000
58 Operating Instructions, 01/2022, A2B00077300-11
