Siemens SCALANCE XB-000 User Manual

Technical speci󹪝cations
CoS acc. to IEEE 802.1Q Yes
QoS priority queues 8
IEEE 802.1Q tags (VLAN ID, priority)
transparent forwarding
Yes
Maximum frame size 1536 bytes
Forwarding of PRP frames (Parallel Re‐
dundancy Protocol)
Yes
Note
The number of IE switches of the SCALANCE XB-000 product line connected in a line in󹪞uences
the frame delay.
When a frame passes through IE switches of the SCALANCE XB‑000 product line, it is delayed by
the store and forward function of the switch
• with a 64 byte frame length by approx. 10 microseconds (at 100 Mbps)
• with a 1500 byte frame length by approx. 130 microseconds (at 100 Mbps)
This means the more devices of the SCALANCE XB‑000 product line that the frame passes
through, the longer the frame propagation time.
8.8 SCALANCE XB004-1LDG
Note
Note the article number in the technical speci󹪝cations.
Table 8-10 Technical speci󹪝cations of the SCALANCE XB004-1LDG (6GK5 004-1GM00-1AB2)
Technical speci󹪝cations
Article number
SCALANCE XB004-1LDG 6GK5 004-1GM00-1AB2
Connection to Industrial Ethernet
Quantity 4
Design RJ-45 jacks with MDI‑X pinning
Properties Half / full duplex
Transmission rate 10 / 100 / 1000 Mbps
Optical connectors
Quantity 1
Design SC sockets
Properties Full duplex acc. to 1000Base-LH
Transmission rate 1000 Mbps
Technical speci󹪝cations
8.8 SCALANCE XB004-1LDG
SCALANCE XB-000
76 Operating Instructions, 01/2022, A2B00077300-11
