Technical speci󹪝cations
Permitted cable lengths (Industrial
Ethernet)
Alternative combinations per length range
0 to 55 m
• Max. 55 m IE TP Torsion Cable 4x2 with IE FC RJ45 Plug 180 4x2
• Max. 45 m IE TP Torsion Cable 4x2 with IE FC RJ45 + 10 m TP Cord 4x2 via
IE FC RJ45 Outlet
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable 4x2 with IE FC RJ45 Plug 180 4x2
• Max. 75 m IE FC TP Marine/Trailing Cable 4x2 + 10 m TP Cord 4x2 via IE FC RJ45 Out‐
let
0 to 100 m
• Max. 100 m IE FC TP Standard Cable 4x2 with IE FC RJ45 Plug 180 4x2
• Max. 90 m IE FC TP Standard Cable 4x2 + 10 m TP Cord 4x2 via IE FC RJ45 Outlet
Optical parameters
Cable type Single mode glass FO cable
Cable cross-section 9/125 μm
Permitted cable length 0 to 10,000 m
Attenuation ≤ 0.5 dB/km at 1310 nm
13 dB max. permitted FO cable attenuation with
2 dB link power margin
Electrical data
Power supply Rated voltage 24 V DC
Voltage range 19.2 to 28.8 V DC Safe Extra Low Voltage
(SELV)
Design 3-terminal plug-in block
Current consumption Typical 650 mA
Power loss at 24 V DC Typical 15.6 W
Overvoltage category CAT II
Overvoltage protection at input PTC resettable fuse (1.0 A / 60 V)
Permitted ambient conditions
Ambient temperature During operation -10 ℃ to +60 ℃
During storage -40 ℃ to +80 ℃
During transportation -40 ℃ to +80 ℃
Relative humidity During operation ≤ 95% without condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. +60 °C
ambient temperature
< 3,000 m above sea level at max. +55 °C
ambient temperature
< 4,000 m above sea level at max. +50 °C
ambient temperature
Design, dimensions and weight
Immunity EN 61000-6-2
Emission EN 61000-6-4
Degree of protection IP20
MTBF (EN/IEC 61709; 40 °C) 146 years
Housing material Polycarbonate (plastic)
Technical speci󹪝cations
8.8 SCALANCE XB004-1LDG
SCALANCE XB-000
Operating Instructions, 01/2022, A2B00077300-11 77
