Siemens SCALANCE XB-000 User Manual

XB004-1 XB004‑2 XB004-
1LD
XB004-
2LD
XB005 XB008 XB004-
1G
XB004-
1LDG
XB005G XB008G
TP (RJ-45)
Gigabit Ether‐
net 10 / 100 /
1000 Mbps
- - - - - - 4 4 5 8
Fiber multi‐
mode (SC)
Gigabit Ether‐
net 1000 Mbps
- - - - - - 1 0 - -
Fiber single
mode (SC)
Gigabit Ether‐
net 1000 Mbps
- - - - - - 0 1 - -
Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to the
speci󹪝cation.
If you use damaged parts, this can lead to the following problems:
• Injury to persons
• Loss of the approvals
• Violation of the EMC regulations
• Damage to the device and other components
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
Components of the product
The following components are supplied with a SCALANCE XB-000:
• IE switch SCALANCE XB-000
• 3-pin terminal block (power supply)
• Product information
Description of the device
4.2 Product overview
SCALANCE XB-000
Operating Instructions, 01/2022, A2B00077300-11 15
