Technical speci󹪝cations
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Optical parameters
Cable type Multimode glass FO cable, cable cross sections 62.5/125 μm and 50/125 μm
Permitted cable length (glass FO cable) Cable cross-section Permitted cable length
• 62.5/125 μm
• 50/125 μm
• 0 to 4,000 m
• 0 to 5,000 m
Electrical data
Power supply Rated voltage 24 V DC
Voltage range 19.2 to 28.8 V DC Safe Extra Low Voltage
(SELV)
Design 3-terminal plug-in block
Current consumption Typically 24 V DC 165 mA
E󹪜ective power loss Typically 24 V DC 4 W
Overvoltage protection at input PTC resettable fuse (0.5 A / 60 V)
Permitted ambient conditions
Ambient temperature During operation -10 ℃ to +60 ℃
During storage -40 ℃ to +80 ℃
During transportation -40 ℃ to +80 ℃
Relative humidity During operation ≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. +60 °C
ambient temperature
< 3,000 m above sea level at max. +55 °C
ambient temperature
< 4,000 m above sea level at max. +50 °C
ambient temperature
Design, dimensions and weight
Immunity EN 61000-6-2
Emission EN 61000-6-4
Degree of protection IP20
MTBF (EN/IEC 61709; 40 °C) 95 years
Housing material Polycarbonate (plastic)
Weight 205 g
Dimensions (W x H x D) 45 x 100 x 87 mm
Installation options
• Mounting on a DIN rail
• Wall mounting
Switching properties
Aging time 45 seconds
Max. number of learnable MAC ad‐
dresses
1024
Response to LLDP frames Blocking
Response to spanning tree BPDU
frames
Forwarding
Technical speci󹪝cations
8.2 SCALANCE XB004-2
SCALANCE XB-000
60 Operating Instructions, 01/2022, A2B00077300-11
