Technical speci󹪝cations
0 to 85 m
• Max. 85 m IE FC TP Marine/Trailing Cable with IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing Cable + 10 m TP Cord via IE FC RJ45 Outlet
0 to 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Optical parameters
Cable type Single mode glass FO cable
Cable cross-section 9/125 μm
Permitted cable length 0 to 26,000 m
Attenuation ≤ 0.5 dB/km at 1310 nm
14 dB max. permitted FO cable attenuation with
2 dB link power margin
Electrical data
Power supply Rated voltage 24 V AC, 50/60 Hz
1)
24 V DC
Voltage range 19.2 to 28.8 V AC/DC Safety Extra Low Volt‐
age (SELV)
Design 3-terminal plug-in block
Current consumption Typically 24 V AC 210 mA
Typically 24 V DC 95 mA
E󹪜ective power loss Typically 24 V AC 5.1 VA
Typically 24 V DC 2.3 W
Overvoltage protection at input PTC resettable fuse (0.5 A / 60 V)
Permitted ambient conditions
Ambient temperature During operation -10 ℃ to +60 ℃
During storage -40 ℃ to +80 ℃
During transportation -40 ℃ to +80 ℃
Relative humidity During operation ≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. +60 °C
ambient temperature
< 3,000 m above sea level at max. +55 °C
ambient temperature
< 4,000 m above sea level at max. +50 °C
ambient temperature
Design, dimensions and weight
Immunity EN 61000-6-2
Emission EN 61000-6-4
Degree of protection IP20
MTBF (EN/IEC 61709; 40 °C) 130 years
Housing material Polycarbonate (plastic)
Weight 165 g
Dimensions (W x H x D) 45 x 100 x 87 mm
Technical speci󹪝cations
8.3 SCALANCE XB004-1LD
SCALANCE XB-000
62 Operating Instructions, 01/2022, A2B00077300-11
