Siemens SCALANCE XB-000 User Manual

Technical speci󹪝cations
Power supply Rated voltage 24 V DC
Voltage range 19.2 to 28.8 V DC Safe Extra Low Voltage
(SELV)
Design 3-terminal plug-in block
Current consumption Typical 190 mA
Power loss at 24 V DC Typical 4.6 W
Overvoltage category CAT II
Overvoltage protection at input PTC resettable fuse (1.0 A / 60 V)
Permitted ambient conditions
Ambient temperature During operation -10 ℃ to +60 ℃
During storage -40 ℃ to +85 ℃
During transportation -40 ℃ to +85 ℃
Relative humidity During operation ≤ 95 % no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. +60 °C
ambient temperature
< 3,000 m above sea level at max. +55 °C
ambient temperature
< 4,000 m above sea level at max. +50 °C
ambient temperature
Design, dimensions and weight
Immunity EN 61000-6-2
Emission EN 61000-6-4
Degree of protection IP20
MTBF (EN/IEC 61709; 40 °C) 217 years
Housing material Polycarbonate (plastic)
Weight 188 g
Dimensions (W x H x D) 45 x 100 x 87 mm
Installation options
• Mounting on a DIN rail
• Wall mounting
Switching properties
Aging time 45 seconds
Max. number of learnable MAC ad‐
dresses
16000
Response to LLDP frames Blocking
Response to spanning tree BPDU
frames
Forwarding
CoS acc. to IEEE 802.1Q Yes
QoS priority queues 8
IEEE 802.1Q tags (VLAN ID, priority)
transparent forwarding
Yes
Maximum frame size 1536 bytes
Forwarding of PRP frames (Parallel Re‐
dundancy Protocol)
Yes
Technical speci󹪝cations
8.10 SCALANCE XB008G
SCALANCE XB-000
Operating Instructions, 01/2022, A2B00077300-11 87
