5HPHPEHUPLQLPXPEHQGLQJUDGLXV
Figure 9-2 Dimension drawing, side view (example: SCALANCE XB004-1)
Note
The minimum bending radius of the optical and electrical signal cables used must not be fallen
below.
Example:
SIMATIC NET FO standard cable - bending radius ≥ 70 mm
Dimension drawings
SCALANCE XB-000
90 Operating Instructions, 01/2022, A2B00077300-11
