Siemens SCALANCE XR324WG - 240 VAC Variant

Technical specifications
7.2 Technical specifications of the SCALANCE XR328-4C WG
SCALANCE XR-300WG
Operating Instructions, 05/2017, C79000-G8976-C454-01
53
7.2.2
240 VAC variant
The following technical specifications apply to the 240 VAC variant of the SCALANCE
XR328-4C WG.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors
Quantity
24
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Combo ports
Quantity
4
Electrical connect-
ors
Quantity
4
Connector
RJ-45 jack
Properties
Half/full duplex, MDI-X pinning
Transmission speed
10 / 100/ 1000 Mbps
Slots for pluggable
transceivers
Quantity
4
Connector
SFP transceiver
Transmission speed
1000 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
Design
Socket, 3 pin
Rated voltage
100 to 240 VAC
Voltage range
85 to 264 VAC
Frequency
50 Hz to 60 Hz
Frequency range
47 Hz to 63 Hz
Properties
Not implemented redundantly
Fusing
4 A / 250 V
Current consumption At 100 VAC 150 mA
At 240 VAC 65 mA
Effective power loss
15 W
Permitted ambient conditions
Ambient temperature
1)
During operation up to 3000 m
0 ℃ to +60 ℃
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation at 25 ℃
≤ 95 % no condensation
Housing, dimensions and weight
Design
Rack
Housing material
Metal
Degree of protection
IP30
Dimensions (W x H x D)
482.6 x 43.6 x 177 mm
