Page #57 background imageLoading...
Page #57 background image
Technical specifications
7.4 Mechanical stability (in operation)
SCALANCE XR-300WG
Operating Instructions, 05/2017, C79000-G8976-C454-01
57
7.4
Mechanical stability (in operation)
The following technical specifications apply to the following devices:
SCALANCE XR324WG
SCALANCE XR328-4C WG
IEC 60068-2-27 shock
IEC 60068-2-6 vibration
15 g, 11 ms duration
6 shocks per axis
10 - 58 Hz: 0.075 mm
85 - 150 Hz: 1 g
1 octave/min, 20 sweeps
7.5
Cable lengths
The cable lengths listed below apply to the SCALANCE XR-300WG.
Cable
Permitted cable length
IE TP torsion cable
with IE FC Outlet RJ-45 + 10 m TP cord
0 to 45 m
+ 10 m TP cord
IE TP torsion cable
with IE FC RJ-45 Plug 180
0 to 55 m
IE FC TP Marine / Trailing / Flexible cable
with IE FC Outlet RJ-45 + 10 m TP cord
0 to 75 m
+ 10 m TP cord
IE FC TP Marine / Trailing / Flexible cable
with IE FC RJ-45 Plug 180
0 to 85 m
IE FC TP standard cable
with IE FC Outlet RJ-45 + 10 m TP cord
0 to 90 m
+ 10 m TP cord
IE FC TP standard cable
with IE FC RJ-45 Plug 180
0 to 100 m
7.6
Switching properties
The switching properties listed below apply to the SCALANCE XR-300WG.
Switching properties
Aging time
Can be configured (default value: 30 seconds)
Maximum frame size
1632
Max. number of learnable ad-
dresses
16382
Response to LLDP frames
Blocking
Response to spanning tree
BPDU frames
Forwarding
CoS acc. to IEEE 802.1Q
Yes
