P0700[2] Selection of command source
Selects digital command source
Unit: - Min: 0 Def: 2 Max: 6
Level 1
Settings:
0=Factory default setting
1=BOP (keypad)
2=Terminal
4=USS on BOP link
5=USS on COM link
6=CB on COM link
Index:
P0700[0]: VSD in Auto mode P0700[1]: VSD in Hand mode
Note:
Changing this parameter resets (to default) all settings on item selected. For example: Changing form 1 to 2 resets all
digital inputs to default settings
P0701[2] Function of digital input 1
Selects function of digital input 1
Unit: - Min: 0 Def: 1 Max: 99
Level 2
Settings:
0=Digital input disabled
1=ON/OFF1
2=ON reverse /OFF1
3=OFF2 - coast to standstill
4=OFF3 - quick ramp-down
9=Fault acknowledge
10 =JOG right
11=JOG left
12=Reverse
13=MOP up (increase freq.)
14=MOP down (decrease freq.)
15=Fixed setpoint (direct selection)
16=Fixed setpoint (direct selection + ON)
17=Fixed setpoint (binary coded selection+ON)
25=DC brake enable
26=Enable essential service
27=Enable PID
28=Bypass mode command input
29=External trip
33=Disable additional freq setpoint
99=Enable BICO parameterization
Index:
P0701[0]: VSD in Auto mode P0701[1]: VSD in Hand mode
Dependency:
Setting 99 (enable BICO parameterization) requires P0700 (command source) or P3900 (end of quick commission-
ing)=1, 2 or P0970 (factory reset)=1 in order to reset
Note:
Setting 99 (BICO) for expert use only
P0702[2] Function of digital input 2 Level 2
Selects function of digital input 2
Unit: - Min: 0 Def: 12 Max: 99
Detail:
See P0701 (function of digital input1)
P0703[2] Function of digital input 3 Level 2
Selects function of digital input 3
Unit: - Min: 0 Def: 9 Max: 99
Detail:
See P0701 (function of digital input1)
P0704[2] Function of digital input 4 Level 2
Selects function of digital input 4
Unit: - Min: 0 Def: 15 Max: 99
Detail:
See P0701 (function of digital input1)
P0705[2] Function of digital input 5 Level 2
Selects function of digital input 5 (via analog input)
Unit: Min: 0 Def: 15 Max: 99
Detail:
See P0701 (function of digital input1)
P0706[2] Function of digital input 6 Level 2
Selects function of digital input 6 (via analog input)
Unit: _ Min: 0 Def: 29 Max: 99
Detail:
See P0701 (function of digital input1)
P0707[2] Function of digital input 7
Selects function of digital input 7 (via analog input)
Unit: - Min: 0 Def: 0 Max: 99
Level 3
Settings:
0=Digital input disabled
1=ON/OFF1
2=ON reverse /OFF1
3=OFF2 - coast to standstill
4=OFF3 - quick ramp-down
9=Fault acknowledge
10 =JOG right
11 =JOG left
12 =Reverse
13 =MOP up (increase freq.)
14 =MOP down (decrease freq.)
25 =DC brake enable
26 =Enable essential service
29 =External trip
33 =Disable additional freq. setpoint
99 =Enable BICO parameterization
Index:
P0707[0]: VSD in Auto mode P0707[1]: VSD in Hand mode
Dependency:
Signals about 4 V are active, signals below 1.6 V are inactive
Note:
Signals above 4 V are active, signals below 1.6 V are inactive
P0708[2] Function of digital input 8
Selects function of digital input 8 (via analog input)
Unit: - Min: 0 Def: 0 Max: 99
Level 3
Detail:
See P0707 (function of digital input7)
P0718 CO/BO: Hand / Auto
Mode after startup
Unit: - Min: 0 Def: 0 Max: 1
Level 3
r0722 CO/BO: Binary input values
Displays status of digital inputs
Unit: - Min: - Def: - Max: -
Level 3
Bit fields:
Bit00 Digital input 1 0 OFF, 1 ON
Bit01 Digital input 2 0 OFF, 1 ON
Bit02 Digital input 3 0 OFF, 1 ON
Bit03 Digital input 4 0 OFF, 1 ON
Bit04 Digital input 5 0 OFF, 1 ON
Bit05 Digital input 6 0 OFF, 1 ON
